Superior Double Wall Tank - 500DW
- Description
-
Details
500 Gallon Rectangular Double Wall Tank - Additional Information
-
Additional Information
Classification Double Wall Tank Manufacturer Superior Storage Tanks SKU 500DW Design Features Double wall design for secondary containment – To Protect Our Environment.
Constructed & Tested to UL® 142 Standards.
Perfect for lube applications, chemical, diesel & other flammable liquid storage.
Custom sizes available for specific space or gallon requirements.
Support channels under tank.
One year limited manufacturer's warranty on material and craftsmanship.
Emergency vent openings standard (UL® 142 required).
Always consult with local fire and code enforcement for tank requirements for your application and needs.
Support channels under tank.Dimensions (L x W x H) 109" x 34" x 36"
* Note: An additional 3" on each side will be added to the width of each tank due to the extended tank support *Weight (lbs) 1175 lbs. Notes Superior Double Wall tank meets all requirements of NFPA 30. - Downloads
-
PDF Downloads
- Tank Drawing - 500DW
- Tank Drawing - 500DW
