Reelcraft Hose Reel - F7925-OLP

Reelcraft Hose Reel - F7925-OLP

Reelcraft Hose Reel - F7925-OLP
3/4" x 25' Low Pressure Hose Reel Assembly for Fuel
Product Options
Model# Description
F7900-OLP 3/4" x 25' Low Pressure Reel without Hose for Fuel
Description

Details

3/4" x 25' Low Pressure Hose Reel Assembly for Fuel
Additional Information

Additional Information

Classification Hose Reel
Manufacturer Reelcraft
Model F7925-OLP
SKU F7925-OLP
Design Features - Robust latching mechanism - Latch and ratchet are made of heavy duty cast aluminum with substantial surface area to limit the opportunity for premature water
- Full flow stress swivel design - The full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life
- Long life drive spring - Declutching arbor virtually eliminates possibility of spring damage due to reverse winding. Only the highest quality spring steel is used and conditioned to insure there are no imperfections offering maximum service life.
- Quality finish and corrosion resistant - Individually powder coated components offer the maximum protection from premature corrosion

- Series F7000 reels are supplied with our ball-bearing style swivel
Compatibility Gas and Diesel
Dimensions (L x W x H) 19.75" x 7" x 20.25"
Input 3/4" NPTF
Output 3/4" NPTF
Applications Industrial
Automotive Service Centers
Transmission Shops
Fleet Maintenance Facilities
Pneumatic Tools
Aircraft Maintenance
Tire Stores
Agriculture
Service Trucks
Wash Down
Weight (lbs) 47 lbs
Specifications Series: F7000 Hose Included: Yes
Max. Hose Length (ft): 25
Pressure (psi): 50
Max. Temperature (F): 150

Fluid Path Materials:
Seal Type: Viton
Swivel Material: Steel
Shaft Material: Steel
Product Options
  • Reelcraft Hose Reel - F7900-OLP
  • Classification: Hose Reel
  • Manufacturer: Reelcraft
  • Model: F7900-OLP
  • SKU: F7900-OLP
  • Design Features: - Robust latching mechanism - Latch and ratchet are made of heavy duty cast aluminum with substantial surface area to limit the opportunity for premature water
    - Full flow stress swivel design - The full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life
    - Long life drive spring - Declutching arbor virtually eliminates possibility of spring damage due to reverse winding. Only the highest quality spring steel is used and conditioned to insure there are no imperfections offering maximum service life.
    - Quality finish and corrosion resistant - Individually powder coated components offer the maximum protection from premature corrosion

    - Series F7000 reels are supplied with our ball-bearing style swivel
  • Compatibility: Fuel
  • Dimensions (L x W x H): 19.75" x 7" x 20.25"
  • Input: 3/4" NPTF
  • Output: 3/4" NPTF
  • Applications: Industrial
    Automotive Service Centers
    Transmission Shops
    Fleet Maintenance Facilities
    Pneumatic Tools
    Aircraft Maintenance
    Tire Stores
    Agriculture
    Service Trucks
    Wash Down
  • Mounting: Mobile and Permanent Mount Applications
  • Weight (lbs): 45 lbs
  • Specifications: Series: F7000 Hose Included: No
    Max. Hose Length (ft): 25
    Pressure (psi): 500
    Max. Temperature (F): 210

    Fluid Path Materials:
    Seal Type: Viton
    Swivel Material: Steel
    Shaft Material: Steel
