Husky Automatic Shut-Off Nozzle - 503010N-03

Husky Automatic Shut-Off Nozzle - 503010N-03

Husky Automatic Shut-Off Nozzle - 503010N-03
1" Diesel Truck Stop Nozzle with Three Notch Hold Open Clip and Waffle Splash Guard without Bushing
Product Options
Model# Description
045703N-03 1" Diesel Nozzle with Three Notch Hold Open Clip, Full Grip Guard and Hook
177610-03 1" Diesel Nozzle with Three Notch Hold Open Clip, Waffle Splash Guard, and Spout Bushing
173310N-03 1" Diesel Nozzle with Three Notch Hold Open Clip, Waffle Splash Guard, and Spout Bushing
Description

Details

1" Diesel Truck Stop Nozzle with Three Notch Hold Open Clip and Waffle Splash Guard without Bushing
Additional Information

Additional Information

Classification Nozzle
Manufacturer Husky
Model 503010N-03
SKU 503010N-03
Design Features VIII nozzle shuts off when the gas tank is full.

Spout is reinforced with thick aluminum bushing that retains spout spring and keeps spout from rounding-in: the two leading causes of clicking off and splash-back spillage.

Equipped with a unique Flo-Stopâ„¢ device that shuts off the nozzle if it falls from the fill tank or raises above the horizontal.

Comes standard with full grip guard and waffle splash guard.
Applications For truck stop and other high volume full-service, self-service and unattended stations
Weight (lbs) 3.9 lbs
Material of Construction Body: Aluminum
Seals: Fluorocarbon
Packing: Double O-ring seal protected by fiber reinforced Teflon®
Lever: One piece contoured steel
Product Options
  • Husky Automatic Shut-Off Nozzle - 045703N-03
  • Classification: Nozzle
  • Manufacturer: Husky
  • Model: 045703N-03
  • SKU: 045703N-03
  • Design Features: 1GS nozzle shuts off when the gas tank is full.

    Equipped with unique Flo-Stopâ„¢ device that shuts off the nozzle if it falls from the fill tank or raises above the horizontal.

    Not for use with gravity tanks.

    Not legal for retail dispensing applications.
  • Input: 1" NPTF
  • Weight (lbs): 3.6 lbs
  • Material of Construction: Body: Aluminum
    Seals: Fluorocarbon
    Packing: Double O-ring seal protected by fiber reinforced Teflon®
    Lever: One piece contoured steel with hard plastic cover
  • Husky Automatic Shut-Off Nozzle - 177610-03
  • Classification: Nozzle
  • Manufacturer: Husky
  • Model: 177610-03
  • SKU: 177610-03
  • Design Features: VIIIS Nozzle Shuts-Off when:
    - the pump shuts off.
    - the gas tank is full.
    - the lever is opened before the pump is turned on.
    - when the leak detector has not completed the test cycle.

    Spout is reinforced with thick aluminum bushing that retains spout spring and keeps spout from rounding-in: the two leading causes of clicking off and splash-back spillage.

    Equipped with unique Flo-Stop device that shuts off the nozzle if it falls from the fill tank or raises above the horizontal.

    Comes standard with smooth full grip guard and waffle splash guard.
  • Input: 1" NPTF
  • Box Contents: Nozzle
  • Weight (lbs): 4.6 lbs
  • Material of Construction: Body: Aluminum
    Seals: Fluorocarbon
    Packing: Double O-ring seal protected by fiber reinforced Teflon®
    Lever: One piece contoured steel
  • Husky Automatic Shut-Off Nozzle - 173310N-03
  • Classification: Nozzle
  • Manufacturer: Husky
  • Model: 173310N-03
  • SKU: 173310N-03
  • Design Features: VIII nozzle shuts off when gas tank is full.

    Spout is reinforced with thick aluminum bushing that retains spout spring and keeps spout from rounding-in: the two leading causes of clicking off and splash-back spillage.

    Equipped with a unique Flo-Stop device that shuts off the nozzle if it falls from the fill tank or raises above the horizontal.

    Comes standard with full grip guard and waffle splash guard.
  • Input: 1"
  • Box Contents: Nozzle
  • Applications: For truck stop and other high volume full-service, self-service, and unattended stations
  • Weight (lbs): 3.9 lbs
  • Material of Construction: Body: Aluminum
    Seals: Fluorocarbon
    Packing: Double O-ring seal protected by fiber reinforced Teflon®
    Lever: One piece contoured steel
